This product provides lifting and angle adjustment functions for snowplows, snow removal machine and can control one double-acting cylinder and two single-acting cylinders at the same time.
The hydraulic power pack is composed of high-pressure DC motor, multi-purpose integrated block, hydrauli valve, oil tank and other parts. Providing lifting and angle adjustment functions for snow sweepers. It can control one double-acting cylinder and two single-acting cylinders at the same time.
| Model | DC-F36-1.6/F-1.6-12/**-5H-C |
| Voltage | DC 12V |
| Power | 1.6kW |
| Speed | 2600rpm |
| Disp. | 1.6 cc/r |
| Pressure | 20 MPa |
| Volume | 5L |
| Size | G1/4 |
RYAN snow sweeper power packs 1 are widely used in aerial work platform and automobile tail gate.
