The performances of Group 2 available are: displacement 4.2cc – 39 cc, maximum pressures up to 300 bar.
Reliable and stable; even at the low speed.
| Model | Displacment (ml/r) | Pressure(bar) | Speed(r/min) | L1 (mm) | L (mm) | Inlet | Outlet | |||
| Rated | Max. | Rated | Max. | Min. | ||||||
| 2ABPF04L04S13D10L-TLT | 4 | 200 | 250 | 2000 | 3500 | 500 | 43.4 | 89.8 | G1/2 | G1/2 |
| 2ABPF4.5L04S13D10L-TLT | 4.5 | 200 | 250 | 2000 | 3500 | 500 | 43.8 | 90.6 | ||
| 2ABPF06L04S13D10L-TLT | 6 | 200 | 250 | 2000 | 3500 | 500 | 45.3 | 93.5 | ||
| 2ABPF08L04S13D10L-TLT | 8 | 200 | 250 | 2000 | 3500 | 500 | 46.8 | 96.5 | ||
| 2ABPF10L04S13D10L-TLT | 10 | 200 | 250 | 2000 | 3500 | 500 | 48.5 | 100.0 | ||
| 2ABPF12L04S13D10L-TLT | 12 | 200 | 250 | 2000 | 3500 | 500 | 50.3 | 103.5 | ||
| 2ABPF14L04S13D10L-TLT | 14 | 200 | 250 | 2000 | 3500 | 500 | 51.8 | 106.5 | ||
| 2ABPF16L04S13D10L-TLT | 16 | 200 | 250 | 2000 | 3500 | 500 | 53.5 | 110.0 | ||
| 2ABPF18L04S13D10-TLT | 18 | 200 | 250 | 2000 | 3500 | 500 | 55.3 | 113.5 | ||
| 2ABPF20L04S13D10L-TLT | 20 | 200 | 250 | 2000 | 3500 | 500 | 57.0 | 117.0 | ||
| 2ABPF23L04S13D10-TLT | 23 | 200 | 250 | 2000 | 3000 | 500 | 59.3 | 121.5 | ||
| 2ABPF25L04S13D10L-TLT | 25 | 160 | 200 | 2000 | 3000 | 500 | 61.0 | 125.0 | ||
| 2ABPF28L04S13D10L-TLT | 28 | 160 | 200 | 2000 | 3000 | 500 | 63.5 | 130.0 | ||
| 2ABPF30L04S13D10L-TLT | 30 | 160 | 200 | 2000 | 3000 | 500 | 65.0 | 133.0 | ||
RYAN Group 2 series gear pumps are widely used in forklift，harvester，tractor，aerial work platform and road roller.
