RYAN Group 1 series gear pumps in aluminum and with external gears, belonging to displacement size Group 1. You can choose between standard, at separate-stages, single inlet and shaped pumps.
The displacement ranges from 1.1 cc to 8 cc, maximum pressures up to 300 bar. We have single pump, tandem pumps and multiple pumps available.
| Model | Displacement (ml/r) | Pressure(bar) | Speed(r/min) | L(mm) | |||
| Rated | Peak | Rated | Max. | Min. | |||
| 1QEPF0.8K06T48SP6 | 0.8 | 200 | 250 | 3000 | 4000 | 500 | 80.3 |
| 1QEPF1.1K06T48SP6 | 1.1 | 200 | 250 | 3000 | 4000 | 500 | 80.8 |
| 1QEPF1.6K06T48SP6 | 1.6 | 200 | 250 | 3000 | 4000 | 500 | 82.8 |
| 1QEPF2.5K06T48SP6 | 2.5 | 200 | 250 | 3000 | 4000 | 500 | 86.3 |
| 1QEPF3.2K06T48SP6 | 3.2 | 200 | 250 | 3000 | 3500 | 500 | 80.0 |
RYAN Group 1 series gear pumps are widely used in forklift，harvester，tractor，aerial work platform and road roller.
